C&D Pure Lead Max Series

C&D Pure Lead Max Series

$490.10 – $1,692.22

Engineered with patented pure lead alloy and advanced catalyst technology, the new Pure Lead Max batteries deliver longevity and performance for your Data Center and UPS needs. Backed by a 8-year warranty, they offer a reliable, cost-effective solution by serving as a single replacement over a 15-year UPS lifecycle.

Find more product information on the C&D PLM Data Sheet. Contact our support team with questions on installation, service, and preventative maintenance on any UPS battery replacement or battery cabinet system.

SKU: N/A Category:

Description

Engineered with patented pure lead alloy and advanced catalyst technology, the new Pure Lead Max batteries deliver longevity and performance. Backed by an industry-leading 8-year warranty, they offer a reliable, cost-effective solution by serving as a single replacement over a 15-year UPS lifecycle.

Model Terminal Maximum Discharge Current (Amps) Short Circuit Current (Amps @ 0.1 sec) Terminal Type Terminal Torque Length (in) Width (in) Height (in) Weight (lbs)
UPS12-305PLM Top 800 3600 1/4-20 UNC 110 in.-lbs. (12.4 N-m) 10.3 6.8 8.0 58.4
UPS12-355PLM Top 800 4200 1/4-20 UNC 110 in.-lbs. (12.4 N-m) 12.0 6.8 8.1 67.4
UPS12-405PLM Top 800 4700 1/4-20 UNC 110 in.-lbs. (12.4 N-m) 13.4 6.8 8.5 75.8
UPS12-495PLM Top 800 5000 1/4-20 UNC 110 in.-lbs. (12.4 N-m) 13.6 6.8 10.9 100.0
UPS12-545PLM Top 800 5000 1/4-20 UNC 110 in.-lbs. (12.4 N-m) 13.6 6.8 10.9 100.0
UPS12-605PLM Top 800 5000 1/4-20 UNC 110 in.-lbs. (12.4 N-m) 13.6 6.8 10.9 109.0
UPS12-675PLMF Front 800 5100 1/4-20 UNC 110 in.-lbs. (12.4 N-m) 22.0 4.9 11.0 124.6
UPS12-705PLMF Front 900 5500 1/4-20 UNC 110 in.-lbs. (12.4 N-m) 22.0 4.9 12.6 149.0
UPS12-1005PLMF Front 1200 6048 Insert (M8) 160 in.-lbs. (18 N-m) 22.0 6.1 12.6 188.0

Key Features

  • 16-year design life
  • Catalyst technology extends service life
  • MSE’s advanced proprietary paste processing for high active material utilization resulting in low float current
  • Patented Long-Life Alloy in the grids to minimize grid growth, reduce gassing, and extend battery life
  • Available in both Top terminal and TFA (True Front Access) formats
  • Our TFA design maximizes energy density and minimizes internal resistance by providing a direct connection from the plates to the terminals
  • Patented UL recognized flame-arresting vents in each cell for safety
  • Thermally welded and helium leak tested case-to-cover bond ensures a robust leak proof seal
  • Can be operated in any orientation
  • Published rates down to 1 minute

Additional information

Weight N/A
Dimensions N/A
Model

UPS12-1005PLMF, UPS12-305PLM, UPS12-355PLM, UPS12-405PLM, UPS12-495PLM, UPS12-545PLM, UPS12-605PLM, UPS12-675PLMF, UPS12-705PLMF
